| Gewicht |
24.10 |
| Farbe |
liquidblue´n´blue |
| Farbzuordnung |
Blau |
| Rahmenform |
Diamant |
| Ganganzahl |
12 |
| Schaltart |
Kettenschaltung, mech. |
| Akkuposition |
intube |
| Motorposition |
Mittelmotor |
| Gabelhersteller |
Fox |
| Federung |
luftgefedert |
| Bremssystem |
Scheibenbremse, hydraulisch |
| Rahmenmaterial |
Aluminium |
| Schaltung |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Drehmoment (Nm) |
85 |
| Motorhersteller |
Bosch |
| Griffe |
ACID Disrupt, Soft Compound |
| Kette |
Shimano CN-M6100 |
| Steuersatz |
ACROS AZF-1035,BlockLock 120°, Top Zero-Stack 1 1/2(ZS 56mm), Bottom Zero-Stack 1 1/2(ZS 56mm) |
| Bremse |
Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| Sattelklemmung |
CUBE Screwlock Semi Integrated, 34.9mm |
| Dämpfer |
Fox Float DPS EVOL, 205x60mm (27.5: 185x55mm), Open/Medium/Firm Mode, Trunnion Mount |
| Sattelstütze |
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| Lenker |
Newmen Evolution SL 318.25, 780mm |
| Schalthebel |
Shimano Deore SL-M6100-IR, Rapidfire-Plus |
| Zahnkränze |
Shimano Deore CS-M6100, 10-51T |
| Gabel |
Fox 34 Float Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, E-Bike Optimized, 150mm |
| Vorbau |
CUBE Performance Stem E-MTB, 31.8mm |
| Sattel |
Natural Fit Venec |
| Kurbelsatz |
ACID E-Crank, 165mm (27.5: 36T // 29: 34T) |
| Motor |
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System |
| Display |
Bosch Kiox 300 |
| Akkuleistung (Wh) |
750 |
| Akku |
Bosch PowerTube 750 |
| Modelljahr |
2023 |
| Kategorie |
E-Bike Fully / E-Mountainbikes / E-Bikes / Pedelecs |
| Zustand |
neu |
| Laufradgröße |
29,0 |
| Geschlecht |
k.Angabe |
